Custom-designed transducers
The Yamaha CZR12 is loaded with great-sounding, custom-designed transducers. Its high-frequency transducer includes a 2-inch voice coil and 1-inch throat compression driver, a titanium diaphragm, and neodymium magnet housed in a die-cast aluminum frame. Its low-frequency transducer uses a large 3-inch voice coil, cast-aluminum frame, and powerful, yet lightweight, neodymium magnet to handle the chest-thumping low end that the CZR12 delivers. The CZR12 isn't just all about power, however. Its low-end response is tightly controlled, especially in the mid-bass and vocal range, assuring crystal-clear sound reproduction — even at cranked volumes.
Smart, ultra-flexible design
The CZR12 integrates with any configuration, thanks to its ultra-flexible design. Its rotatable horn allows vertical or horizontal mounting. Benefit from a 90x60° dispersion from a vertical position. Enjoy smooth, level coverage, by virtue of the CZR12's constant directivity horn — its innovative design minimizes the roll-off that conventional horns often produce.
Sophisticated DSP processing
If you power the CZR12 with a Yamaha PX Series amplifier, you can take full advantage of its dedicated speaker processor tuning settings. Fine-tune output channels with equalization, and add limiting to protect your speakers from dangerous signal spikes. Dial in crossovers to integrate subwoofers and fill speakers. Use the built-in delay network to ensure phase coherency across all speakers in larger rigs. And all of these advanced features are easily accessible from the LCD display.
Yamaha CZR12 Features:
- 2-way passive loudspeaker with 2" HF and 12" LF drivers
- Boasts 1,600-watt power handling and bi-amp capabilities
- 38Hz-20kHz frequency range with 129dB SPL
- Great-sounding, custom-designed transducers
- Rotatable horn allows vertical or horizontal mounting
- 90x60° dispersion from a vertical position
- Constant directivity horn supplies smooth, level coverage without roll-off
- Compatible with Yamaha PX Series amplifier processor tuning settings (amplifier sold separately)
- Lightweight, yet durable, plywood cabinet with a premium-grade polyurea coating
